SHADES
The ceramic surfaces in this collection become a real palette of colors onto which simple, rhythmic textures in different hues are reproduced, expressed in five cement bases, generating families of pattern nuances. Decorations from the past that blend into the tradition of contemporary décor.
The ceramic surfaces in this collection become a real palette of colors onto which simple, rhythmic textures in different hues are reproduced, expressed in five cement bases, generating families of pattern nuances. Decorations from the past that blend into the tradition of contemporary décor.
The ceramic surfaces in this collection become a real palette of colors onto which simple, rhythmic textures in different hues are reproduced, expressed in five cement bases, generating families of pattern nuances. Decorations from the past that blend into the tradition of contemporary décor.
| Color | Size Availability | Thickness | Finish |
| Noon | 12 x 24, 24 x 24, 24 x 48, 32 x 32, 12 x 24 and 24 x 24 Wash decor, 7 x 8 Hexagon and Blot decor | 8.5 and 9.5mm | Natural |
|---|---|---|---|
| Dawn | 12 x 24, 24 x 24, 24 x 48, 32 x 32, 12 x 24 and 24 x 24 Wash decor, 7 x 8 Hexagon and Blot decor | 8.5 and 9.5mm | Natural |
| Dusk | 12 x 24, 24 x 24, 24 x 48, 32 x 32, 12 x 24 and 24 x 24 Wash decor, 7 x 8 Hexagon and Blot decor | 8.5 and 9.5mm | Natural |
| Evening | 12 x 24, 24 x 24, 24 x 48, 32 x 32, 12 x 24 and 24 x 24 Wash decor, 7 x 8 Hexagon and Blot decor | th>8.5 and 9.5mm | Natural |
| Night | 12 x 24, 24 x 24, 24 x 48, 32 x 32, 12 x 24 and 24 x 24 Wash decor, 7 x 8 Hexagon and Blot decor | 8.5 and 9.5mm | Natural |
| TECHNICAL CHARACTERISTIC | NORM | VALUE REQUIRED | MEAN VALUE | NORM | MEAN VALUE |
| Length and width | ISO 10545.2 | ±0.6% (±2.00 mm) | In accordance | ASTM C-499 | In accordance |
|---|---|---|---|---|---|
| Thickness | ISO 10545.2 | ±5% (±0.5 mm) | In accordance | ASTM C-485 | In accordance |
| Warpages of edges | ISO 10545.2 | ±0.5% (±1.5 mm) | In accordance | ASTM C-502 | In accordance |
| Wedging | ISO 10545.2 | ±0.5% (±2.0 mm) | In accordance | ASTM C-499 | In accordance |
| Flatness | ISO 10545.2 | ±0.5 (±2.00 mm) | In accordance | ASTM C-485 | In accordance |
| Water absorption | ISO 10545.3 | ≤0.5% | In accordance | ASTM C-373 | In accordance |
| Bending strength | ISO 10545.4 | R ≥ 35N/mm² | In accordance | 250 lbs or greater | In accordance |
| Linear thermal expansion between 20° and 100° | ISO 10545.8 | According to builder’s specifications | = 7 x 10-6 C-1 | ||
| Thermal shock resistance | ISO 10545.9 | Request | Resistant | ||
| Frost resistance | ISO 10545.12 | Request | Resistant | ASTM C-1026 | In accordance |
| Resistance to chemical attack | ISO 10545.13 | According to builder’s specifications | Resistant | ASTM C-650 | In accordance |
| Colors resistance to light | DIN 51094 | No alteration | In accordance | ||
| Stain resistance | ISO 10545.14 | Test method available | In accordance | ||
| Slippage resistance | DIN 51130 and DIN 51097 | 9 ≤ R ≤ 13 and A,B,C | ASTM C-1028 COF ≥ 0.6 Dry ≥ 0.6 Wet and ANSI 137.1-2012 DCOF ≥ 0.42 Wet | ||
| Pendulum slip test | BS EN 7976-2 | ›36 Dry ›36 Wet | AS 4586: 2013 Class |
